| Printing Technology |
| Print Method: |
Impact dot matrix |
| Control Panel: |
4 switches and 5 LEDs |
| Print Direction: |
Bi-direction with logic seeking |
| Number of Pins in Head: |
24 pins |
| Control Code: |
ESC/P2 and IBM PPDS emulation |
| Print Speed |
| High Speed Draft: |
10cpi: 347 cps |
|
12cpi: 416 cps |
| Draft: |
10cpi: 260 cps |
|
12cpi: 312 cps |
|
15cpi: 390 cps |
| Letter Quality: |
10cpi: 86 cps |
|
12cpi: 103 cps |
|
15cpi: 129 cps |
| Reliability |
| MTBF: |
Approx. 10,000 POH (25% Duty) |
| Printhead Life: |
Approx. 400 million strokes/wire |
| Mean Print Volume Between Failure (MVBF): |
Approx. 20 million lines (Except print head) |
| Print Characteristics |
| Character Sets: |
Italic table, PC437 (US Standard Europe), PC850 (Multilingual), PC860 (Portuguese), PC861 (Icelandic), PC863 (Canadian-French), PC865 (Nordic), Abicomp, BRASCII, Roman 8, ISO Latin 1, PC 858, ISO 8859-15 |
| Bitmap Fonts: |
Epson Draft: 10, 12, 15 cpi; Epson Roman & San Serif: 10, 12, 15 cpi, Proportional; Epson Courier: 10, 12, 15 cpi; Epson Prestige: 10, 12 cpi; Epson Script, OCR-B, Orator & Orator-S: 10cpi; Epson Script C: Proportional |
| Scalable Fonts: |
Epson Roman, Epson San Serif, Epson Roman T & Epson San Serif H: 10.5pt., 8pt. – 32pt. (every 2pt.) |
| Barcode: |
EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, Postnet |
| Paper Path |
| Manual Insertion: |
Rear in, Top out |
| Push Tractor: |
Rear in, Top out |
| Paper Media |
| Cut Sheet (Single Sheet): |
Length: 100 ~ 364 mm (3.9 ~ 14.3″) |
|
Width: 100 ~ 257 mm (3.9 ~ 10.1″) |
|
Thickness: 0.065 ~ 0.14 mm (0.0025 ~ 0.0055″) |
| Cut Sheet (Multi-part Forms): |
Length: 100 ~ 364 mm (3.9 ~ 14.3″) |
|
Width: 100 ~ 257 mm (3.9 ~ 10.1″) |
|
Thickness: 0.12 ~ 0.32 mm (0.0047 ~ 0.0126″) (Total) |
| Envelope (No.6): |
Length: 92 mm (3.6″), Width: 165 mm (6.5″), Thickness: 0.16 ~ 0.52 mm (0.0063 ~ 0.0205″) (Total) |
| Envelope (No.10): |
Length: 105 mm (4.1″), Width: 241 mm (9.5″), Thickness: 0.16 ~ 0.52 mm (0.0063 ~ 0.0205″) (Total) |
| Continuous Paper (Single Sheet): |
Length: 101.6 ~ 558.8 mm (4.0 ~ 22.0″) |
|
Width: 101.6 ~ 254.0 mm (4.0 ~ 10.0″) |
|
Thickness: 0.065 ~ 0.32 mm (0.0025 ~ 0.0126″) (Total) |
| Continuous Paper (Multi-part Forms): |
Length: 101.6 ~ 558.8 mm (4.0 ~ 22.0″) |
|
Width: 101.6 ~ 254.0 mm (4.0 ~ 10.0″) |
|
Thickness: 0.065 ~ 0.32 mm (0.0025 ~ 0.0126″) (Total) |
| Roll Paper: |
Width: 216 mm (8.5″), Thickness: 0.07 ~ 0.09 mm (0.0028 ~ 0.0035″) |
| General |
| Memory Buffer: |
128KB |
| Supported OS and Applications |
| Supported OS: |
Windows 95 / 98 / 2000 / Me /XP / Vista / 7 / 8 / 8.1 / 10 |
| Utility: |
Epson Status Monitor 3: Microsoft® Windows® 2000 / XP / 7 / 8 / 8.1 / 10 |
|
Epson Printer Setting: Microsoft® Windows® 2000 / XP / 7 / 8 / 8.1 / 10 |
| Dimensions and Weight |
| Dimensions (W x D x H): |
362 x 275 x 154 mm |
| Weight: |
4.1kg |
| Consumables |
| Ribbon Cartridge Black: |
Approx. 2.5 million characters (LQ 10cpi, 48 dots/character) – C13S015639 |
| Options: |
Fabric Ribbon Cartridge (Black) – S015634 |
| Environmental Conditions (Operating) |
| Temperature: |
5 ~ 35°C |
| Humidty: |
10 ~ 80 % RH |
| Acoustic Noise: |
Approx. 53 dB(A) (ISO 7779 pattern) |
| Interface: |
Bi-directional parallel interface (IEEE-1284 nibble mode supported) |
|
USB 2.0 Full-Speed |
